Description
- Horizontal windlasses
- Base in anodized aluminum in hard oxide
- Integrated sensor and magnet for chain counter
- Manual Free-Fall system
- IP67 watertight motor
Easy Installation. The vertical motor allows for extremely simple and quick installation.
| Eagle | 700 W | 7 – 10 m | 23 – 33 ft |
| Eagle | 1000 W | 10 – 13 m | 33 – 43 ft |
| Eagle | 1400 W | 12 – 15 m | 39 – 49 ft |
| Gypsy and Drum | Ø 130 mm / 5″ 1/8 |
| GYPSY | 6 mm | 8 mm – 5/16″” | 10 mm – 3/8″ | |||||
| CHAIN | 6 mm | 6 mm | 8 mm | 8 mm | 5/16″ | 5/16″ | 10 mm | 3/8″ |
| DIN 766 | ISO | DIN 766 | ISO | G4 | BBB | ISO (P.30) | G4 |
Supplied accessories standard
| Contactor units | Technopolymer handle | |||||||||||||
|
Optional accessories
|
Hydraulic magnetic |
UP/DOWN |
Foot |
handheld |
Chain |
Radio remote |
| Standard version | E3 700 D | |
| Motor power | 700 W | |
| Motor supply voltage | 12 V | 24 V |
| Maximum pull | 1070 Kg 2359 lb |
1070 Kg 2359 lb |
| Maximum working load | 300 Kg 661 lb |
370 Kg 816 lb |
| Working load | 100 Kg 220 lb |
125 Kg 276 lb |
| Current absorbtion @ working load (1) | 90 A | 60 A |
| Maximum chain speed (2) | 28,7 m/min 94.2 ft/min |
33,5 m/min 109.9 ft/min |
| Maximum chain speed @ working load (2) | 15,8 m/min 51.8 ft/min |
15 m/min 49.2 ft/min |
| Weight | 22,2 Kg 48.9 lb |
22,2 Kg 48,9 lb |
| 1) | After an initial period of use |
| 2) | Measurements taken with a gypsy for a 8 mm chain |
Dimensions
E3 700/700D
Deck thickness:
25÷50 mm (31/32 ÷1″ 31/32)
On request, shaft and studs can be supplied for greater deck thicknesses.
Dimensions in mm (inch)
Supplied accessories standard
| Contactor units | Technopolymer handle | |||||||||||||
|
Optional accessories
|
Hydraulic magnetic |
UP/DOWN |
Foot |
handheld |
Chain |
Radio remote |
