Description
Phoenix Smart IP43 Charger 12V/30A (1+1) / 200-265VAC/65-65Hz or 250-350VDC / 180x249x100mm / 3.5kg [PSC123051085] Replacement PSC123051095
Product Information
With boat owners in mind this adaptive 5-step charger can provide either 30A or 50A of charge to each of three battery banks. Or the charger 1+1 model provides 3A to the starter-battery, the rest to the ‘house’ bank. 24V models are available with 16A/25A charge. Bluetooth enabled, you can monitor the charger and set alarms straight from your phone. Adaptive, intelligent, dynamic charge features – see the datasheet below.
Models:
12 / 24 Volts
Bluetooth Smart enabled
Any Bluetooth enabled smart phone, tablet or other device can be used to monitor, to change settings and to update the charger when new software features become available.
Phoenix Smart (1+1): two outputs to charge 2 battery banks
The second output, limited to approximately 3A and with a slightly lower output voltage, is intended to top up a starter battery.
Phoenix Smart (3): three full current outputs to charge 3 battery banks
Each output can supply the full rated output current. But the total of the 3 outputs combined can never exceed the current rating of the charger.
Adaptive 5-stage charge algorithm: bulk – absorption – recondition – float – storage
The Phoenix Smart Charger features our well-known ‘adaptive’ battery management system that can be preset to suit different types of batteries. The ‘adaptive’ feature will automatically optimise the charge process relative to the way the battery is being used.
Fully programmable charge algorithm
The charge algorithm can be programmed with help of Bluetooth or the interface. Three preprogramed algorithms can be selected with the mode button.
interface
For a wired data connection to a Colour Control panel, PC or other devices. Please see the VictronConnect app under Downloads / Software on our website.
Datasheet-Phoenix-Smart-IP43-Charger-EN (1)
Manufacturer Part Number: PSC123051085
