Description
- Will withstand the water exposures normally encountered in above deck applications: salt spray, rain, hose washdowns, momentary immersions
- ON-OFF Contura Switches
- ON indicating LEDs embedded in switches
| Specifications | |
|---|---|
| Weatherproof* | Water-Resistant |
| Positions | 3 |
| Nominal Voltage | 12V DC 24V DC |
| Panel Cumulative Rating | 45A |
| Switch Rating | 20A @ 12V DC 15A @ 24V DC |
| Height | 3.75in (95.25 mm) |
| Width | 5.25in (133.35 mm) |
| Depth | 3.00in (76.2 mm) |
| Weight | 0.70Lb (0.32 Kg) |
| Weight | 0.70lb (0.32 kg) |
*Constructed or protected so that exposure to the weather will not interfere with successful operation in rain, spray, and splash
| Included | |
|---|---|
| Qty | Product |
| 3 | Panel Mount AGC/MDL Fuse Holder |
| 1 | Basic DC Panel Label Set – 30 Labels [LABEL] |
| 3 | Contura Switch SPST Gray – OFF-ON |
