Description
Quick Prince DP2E windlass for chain 8mm. 800 watts / 12 volts. Mainly intended for deck mounting in the bow, engine with planetary gear below deck.
Prince DP2E windlass with vertically positioned motor and planetary gear for quick installation. 800 W, for boats between 8-10 m. Wheel for chain 8 mm / three-ply line 12 mm.
Vertical windlass with efficient planetary gear and base in AISI 316 stainless steel and composite. Combination wheel in chromed bronze that takes both rope and chain. Manual free fall system Waterproof motor housing IP66.
Supplied with relay and built-in sensor for chain counter.
•Volts: 12
•Motor power W: 800
•Chain etc.: 8
•Line etc.: 12
•Boat size meters: 8-10
•Maximum drag kg: 820
•Max. working load kg: 290
•Workload kg: 95
•Speed m/min: 22.5
•Weight kg: 8.3
•Suitable Quick fuse A: 80
Add control panel and fuse.
